Pl2303 Eeprom Writer Utility Software

Integrated OTPROM (One-Time Programming ROM) – no external EEPROM required. O For writing and storing customer USB VID/PID, Serial Number, Product String, and other device startup configurations. Feb 26, 2008. This application note provides the latest important migration guidelines for PL-2303HX Edition. USB-to-Serial Bridge. The table below shows the software comparison for all the PL-2303 chip edition series. That the PL-2303HXD is using a newer version (1.0.0.5) for the EEPROM Writer program (see. Nov 27, 2010.

First post here (sorry it's quite a length one). Here's the problem - I have two USB to serial adaptors (identified as using the Prolific PL-2303) which *aren't* identical in appearance but appear the same when detected by OS's. I would like to be able to identify them through software without having to know which adaptor is plugged into which USB bus or whatever. If serial device X is connected to adaptor X and serial device Y connected to adaptor Y, when in linux the kernel can detect an assign these USB devices different device names between reboots. I've compared the devices in Windows Device Manager, and also with 'lsusb -v' in linux and there's little to distinguish between them. I've read the following thread from this forum about being able to reprogram the EEPROM - edaboard.com/thread62529.html - however for adaptor 1 if I leave the eeprom writer program settings as default, change the serial number or the PID and press write, I get an error message 'Compare EEPROM failed!'

Followed by an alert 'Write EEPROM successful!' But it clear isn't as the PID hasn't changed and (although I'm not certain I know where to look for the serial number) the serial number doesn't appear to change either when reviewing device info (nothing seems to change).

Adaptor number 2 - the first time I got it out the box and tried to write to the EEPROM using the writer (same defaults, but just changing the serial number) and didn't get the error message, just the success one! However I don't see anything in either OS that relates to the serial number I supposedly wrote to the device. Since that first time of using the EEPROM writer with that device, I get exactly the same behaviour as adaptor 1 when writing.

When trying to read the EEPROM I get the alert message 'The EEPROM isn't programmed yet!' , confirming the previous writes don't seem to have done anything.

I've also read jethomson.wordpress.com/2010/02/21/diy-usb-to-serial-cable-for-3usd/ which in the last two paragraphs mentions the following from the blog owner: 'I looked into this, but my memory is a bit hazy on the details. IIRC you need a special USB board that puts out 6V to program the EEPROM in the rev. D, and it can only be programmed once.

Charu nivedita books pdf free download for pc. CHARU NIVEDITA BOOKS PDF - HOME BIOGRAPHY BOOKS ARTICLES GALLERY CONTACT. Simple pdf download website without any modern techniques. This article is incomplete. Charu nivedita books Inspire Digital Educational Resources. Get fast, free shipping with Amazon Prime. Our website is secured by niveditx SSL encryption issued by Verisign Incmaking your shopping at Sapnaonline as secure as possible. Charu Nivedita Books. E-Gift Couponxharu here. Books by Charu Nivedita, Kaṭavuḷum nān̲um, Āsāti-- āsāti-- āsāti--, Matumitā con̲n̲a pāmpu kataikaḷ, Kāmarūpa kataikaḷ, Ticai ar̲iyum par̲avaikaḷ, Cin̲imā cin̲imā, Tīrākkātali, Tirakkatali.

A has a 2-wire EEPROM interface though, and I think if you program an external EEPROM correctly you can tell the PL2303 to report itself as High Power device and therefore get 500 mA from the USB port. I keep meaning to try this but never have. If you get it to work, write back and let us know!'

I've also emailed Prolific to ask for access to their versions of the EEPROM writers as one of their product sheets for the 2303 suggests that EEPROM writers between the different versions of the adaptors (X, HX etc) aren't compatible. No response (been about a week now). If anyone has any info to help with this, it would be greatly appreciated - seems I'm running out of things to try. First you should make sure you can't differentiate the two devices by serial number. If not then you should figure out which chip you have.
